Energy chain system: Polymer Rotation Module (PRM)
Complete set includes:
chain links, separators, mounting brackets, strain relief elements and guide trough without glide bar
Dimensions:
Rotation angle up to 360°
Inner height: 10.10mm
Outer height: 15mm
Inner width: 10mm
Outer width: 17.40mm
Bend radius: 18mm
Total system height: 22 mm
Max. cable diameter: 8mm
Applications:
Small measuring and handling machines, camera applications
| Article designation | Example pictures | Quantity |
|---|---|---|
| Chain links for outer diameter: 200mm 300mm 400mm 500mm |  | E2i.10.40.018/040.0 x 14 links E2i.10.10.028/065.0 x 20 links E2i.15.13.048/075.0 x 25 links E4.21.040.048/120.0 x 23 links |
| Mounting bracket for outer diameter: 200mm 300mm 400mm 500mm |  | E2.100.10.34PZ.A1 x 1 set E2.100.10.34PZ.A1 x 1 set E2.150.13.34PZ.A1 x 1 set E4.210.040.1.12.A x 1 set |
| Separators for the outer diameter: 200mm 300mm 400mm 500mm |  | E2.10.5.1, 1 - 3x per link E2.10.5.1, 1 - 3 x per link E2.15.5.1, 1 - 3 x per link T2111, 1 - 2 x per link |
| Strain relief for the outer diameter: 200mm 300mm 400mm 500mm |  | on the mounting bracket on the mounting bracket on the mounting bracket T2113.Z x 2 - 4 units |
| Guide trough without glide bar for outer diameter: 200mm 300mm 400mm 500mm |  | IE14.2.200P.XX.01 x 1 unit IE14.2.300P.XX.01 x 1 unit IE14.2.400P.XX.01 x 1 unit IE14.2.500P.XX.01 x 1 unit |
The PRM rotating energy supply system is a plastic trough for such applications as small measuring and handling machines. The guide is also suitable for camera applications. It requires no sliding contacts and is protected against corrosion.
chainflex cables are unassembled cables for moving applications in cable guides or for robot applications, fail-safe with a 36-month guarantee.
