Name: autoglide 5 - steel cable floor guide - 2400AG5 complete set | Travel: 10 - 60m (PACK.2400.07AG5.075.10000.01)
SKU: PACK.2400.07AG5.075.10000.01
Price: 1120.65 EUR
Availability: InStock

e-chains®

Complete set

autoglide 5 - steel cable floor guide - 2400AG5 complete set | Travel: 10 - 60m

1 complete set consists of:+ Mounting brackets for moving end + Wire rope + Individual parts AG5 and AG + energy chain® + Fixed end module upper run guide + Rope tensioning unit + Guide bracket for AG + Separators every 2nd link, pre-assembled
